Forwell specializes in the production of Automatic Clamp Systems with a wide range of models specially designed to fit your dies and plates. With over 20 years experience in the industry you can rest assured that Forwell will deliver the highest quality clamps for your machining operations.
There are a wide range of different models available but the three most popular automatic clamping systems are the TAX Pneumatic Type Clamp System, the TR 90° Rotating Die Clamp and the TS Swing Type Clamp.
Effects Of Introducing DCSL
Before
After
01
Manual Operation
Automation
02
While Die/Mold changing, it takes long time and manpower to tighten.
Only touch the buttons on the control panel.
03
The tightening force will be different by different operators.
The clamping force is the same. Increased safety.
04
Operators waste much manpower, increased injury happened.
By control panel, operators save manpower and decrease injury happened.
05
No alarm notification while the screws are loosing.
With alarm device, the machine will stop immediately.
System Selection
Forwell specializes in the production of Automatic Clamp Systems with a wide range of models specially designed to fit your dies and plates. With over 20 years experience in the industry you can rest assured that Forwell will deliver the highest quality clamps for your machining operations.
There are a wide range of different models available but the three most popular automatic clamping systems are the TAX Pneumatic Type Clamp System, the TR 90° Rotating Die Clamp and the TS Swing Type Clamp.
The TAX system uses an automatic pneumatic pressure mechanism to individually clamp upper dies. This system is well suited for both smaller and larger hydraulic presses.
Clamp
F
N
P
TAX-4
68
68
24
TAX-6
78
73
16
TAX-10
98
79
6
The TR system uses a hydraulic mechanism with a 90° turning movement to lock molds and dies into position. This heavy duty Clamping System is available in three different models with a clamping force up to 16 tons
Proof Pressure
27.0MPa(275kgf/cm2)
Max Working Pressure
18.1MPa(185kgf/cm2)
Working Pneumatic Range
0.4~0.7(4~7kgf/cm2)
Ambient Temperature Range
-5~60°C
Hydraulic Fluid
ISO VG32~VG56
Model
Clamping force(at 185kgf/cm2)
Requited Qrantity(cc.)
A±1
MIN.B
MIN.C
TR-6
6
32.5
40
75
25
TR-10
10
52.5
50
95
30
TR-16
16
84.0
60
110
35
Model
D
E
F
G
J
K
M
N
PT
Q
R
TR-6
112
70
M8*16 Deep
M12*20 Deep
64
30
32
148
1/4
79
22
TR-10
116
70
M14*30 Deep
M14*30 Deep
84
35
40
158
3/8
89
27
TR-16
120
76
M14*35 Deep
M14*35 Deep
99
40
50
168
3/8
94
32
Model
T
U
V
W
X
kg Maxx
TR-6
235
15
61
108
44
20
TR-10
252
16
74
110
49
25
TR-16
267
16
79
115
54
27
The TAX system uses an automatic pneumatic pressure mechanism to individually clamp upper dies. This system is well suited for both smaller and larger hydraulic presses.
